> 제품소개 > 3000 HDI |
 |
|
- Memory Module PCB
- Build-Up PCB (Mobile Phone PCB)
- LCD PCB (Matrix & Singulated type)
- Other Industrial PCB |
|
|
 |
|
|
- Double scanning method for higher detectability
- PSR inspection capability
- Vacuum suction boat in order to overcome PCB twist
& bow
- Higher Inspection Productivity
- Low Over-Rejection
- Selective use of CAD/CAM interface teach & Golden
board method
- PC based Hardware control
|
|
|
 |
|
Products
inspected |
Memory
Module PCB, Build-Up PCB, LCD PCB, Industrial PCB |
Resolution |
10~20um/pixel |
Inspection
Item |
Plated
Area |
|
Non-plating, Short,
Intrusion, Protrusion,
Discolor, Pit/Pin Hole, Foreign Material, Scratch |
|
|
|
PSR area |
|
Exposed metal, Lump,
Foreign Material |
|
Verification |
PC
based Image Verification System |
CAD/CAM
interface |
Standard
format : Gerber RS274x(*.gbr, *.ger, *.pho) |
Utility |
AC220,
1 phase ,60Hz, 5kgf/cm2, 4kw |
|
 |
|
|
|
- Verification by inspection image
- Higher Verification Productivity
- Easy-To-Use by "go" ked
- Stastical Process Control
- PC based Verify System
- Economical and Efficient verification |
|
|
|
